Monoprice Choice™ Series 16AWG Oxygen-Free Pure Bare Copper Speaker Wire, 50ft

Be the first to review this product

Quick Overview

Monoprice Choice™ Series 16AWG Oxygen-Free Pure Bare Copper Speaker Wire, 50ft

Availability: In stock

Available inventory: 8

Regular Price: $19.87

Special Price: $16.99

Monoprice Choice™ Series 16AWG Oxygen-Free Pure Bare Copper Speaker Wire, 50ft is available for purchase in increments of 1
custom block

Choice Series 16AWG Oxygen-Free Pure Bare Copper Speaker Wire, 50ft



Get the most out of your home audio system with high quality, oxygen-free, pure bare copper speaker wire from Monoprice!

This speaker wire features two conductors made of high purity (greater than 99.95% pure), oxygen-free bare copper. Pure Bare Copper is a superior conductor to the copper clad aluminum (CCA) conductors used in most other inexpensive speaker wire. CCA is only about 68% as conductive as pure bare copper. This additional resistance is added to the impedance of your speakers and can negatively effect the sound.

For the wire to have no audible effect, the total wire resistance should be no more than 5% of the lowest impedance of your speakers. Even speakers rated for a nominal 8-ohms, may dip to as low as 4-ohms at some frequencies, which further reduces the total cable resistance allowed in the wire. Using Pure Bare Copper speaker wire ensures that the total load put on the amplifier remains as close as possible to the impedance curve of your speakers.

For example, a 16AWG 2-conductor Pure Bare Copper speaker wire has a total resistance of 0.803 ohms per 100 feet (both directions must be considered). By comparison, a 16AWG 2-conductor CCA speaker wire has a total resistance of 1.181 ohms per 100 feet. Assuming 4 ohms is the lowest impedance of your speakers, a speaker wire run can be no more 0.2-ohms total. 20 feet of 16AWG Pure Bare Copper would be 0.1606 ohms, well under the 0.2-ohm limit. On the other hand, 20 feet of 16AWG CCA would be 0.2362 ohms, well OVER the 0.2-ohm limit.

One side of the clear outer PVC jacket is marked with an easily visible blue stripe to indicate polarity.



 Question: How many conductors are on this cable?

Answer: Two, one for positive and one for negative.

Question: Which side is positive and which side is negative?

Answer: It doesn't really matter as long as you remain consistant throughout your setup. There is a blue line on one side to help you distinguish one side from the other.

Question: Is this wire directional?

Answer: No. Directional wire is marketing spin to make you think the cables are somehow better.

Question: What is AWG?

Answer: AWG stands for American Wire Gauge. It is a measure of the thickness of the wires inside the cable. Lower numbers represent a thicker cable.

The measurement is the diameter of the cross section of wire. It is expressed as the number of turns required for the width of the bare wire to make 1 inch. So a 12AWG cable would have wires that are 1/12 of an inch thick.

The outer diameter of the cables jacket is not an accurate expression of gauge since manufacturers can simply put a thicker jacket to make a wire appear to have a heavier gauge.

Question: I've heard that the diameter of these wires was less than that of competitors wires of the same gauge. I thought gauge was a standardized measurement, why would the diameters be different?

Answer: AWG (American Wire Gauge) is a standardized form of measurement. Gauge is expressed as the number of turns it takes the wire to equal an inch. So with a 12AWG wire, for instance, the bare wire (no plastic jacket) will take 12 turns around a spool to make a 1 inch wide coil. In other words, simply put, the bare wire is 1/12" wide. A lot of cable manufacturers will wrap their wires in an extra thick PVC jacket or put plastic filtaments between the strands to make the cable appear much thicker than it. But the amount of copper remains the same.

Question: Does higher strand count provide better audio quality?

Answer: There is a lot of spin placed on wires and cables to justify one type or another. The main reason for this is to justify an over inflated price. Fact is, stranding provides flexibility. Solid wire conductors can deliver high audio quality and arguably better run lengths, but would be more brittle and tend to break. One break and you loose connectivity. Stranded cables would be more flexible and a break in one or more lines will not cut the signal flow. But, it doesn''t magically improve audio performance.

Audio quality is influenced more by the quality of the copper. That is better milled, high purity copper will have lower signal resistance and less fluctuation in density which will lead to better signal integrity and more pure audio. All our speaker wires are milled from high quality, oxygen-free copper.

Question: How do I select the proper gauge for my application?

Answer: Different people will have their own opinions about what gauge is proper for what length. The quality of the equipment can also play a factor. The following is a general guide for picking gauges for certain lengths.

0-25ft - 18AWG

25-50ft - 16AWG

50-75ft - 14AWG

75 & up - 12AWG

SKU 2749 - S8-19
Length (ft) 50
Color No
Gauge 16AWG
Type of Boot No
Brand Monoprice
